Airline connections make networks possible. They open up the world, making new destinations available to customers and creating new revenue opportunities for your business.

Connections can dynamically show you all possible global connections for all airlines as they occur in real time, plotting them on a map to highlight key routes and hubs.

The Connections module can dynamically show you all possible global connections for all airlines as they occur in real time and plot these on a map to highlight key routes and hubs.

Global connections analysis help you monitor performance and evaluate routes based on a Quality of Service Index (QSI) and analyse how airline service changes impact connections at any airport.

Gain a competitive advantage in a market that is expanding faster than ever before to answer the following questions.

  • How do airline services impact connections at an airport?
  • What is the impact of increasing or decreasing capacity on certain routes?
  • What carrier connections could I be missing at an airport?
  • Can I customise QSI to analyse my flights?
  • Which airport connections are affected by schedule changes?
READ MORE
bg7

Latest Release : Analyzer 2.7 - Mini Release June 2022

  • Times series – We have changed the format of the time series so that your exported date data retains its structure and does not require you to do any further formatting.

  • Airline and Airport Hover – Integration of reference data on a hover pop up; This allows the display of detailed Airline and Airport information without the need to run a separate report.

Find out more

How to videos

HubSpot Video

See Whats New In Connections



HubSpot Video

Connections Analyser Reports

HubSpot Video

Missed Connections Report

status-icon

USER Guide & Documentation

Download supporting documentation using the links below:

schedules-icon

Get in Touch

Contact Support For Additional Help

Have you tried searching the Forum for help? Click HERE to go there.

FAQs

We recommend customers use Google Chrome. OAG Connections Analyser can be slow or not show correctly on some browsers.

No. the selections you make are simply ways to narrow down the data to meet your requirements. However, we do recommend that you make your query as specific as possible in Connections Analyser as large queries may take a long time to process

Connections Analyser uses OAG’s schedules database to create potential itineraries with connecting flights. Airline schedules data for one year in the future is included, and historical data back to 1996 is available. Real connection times are created using predefined minimum/maximum connecting times as well as the OAG MCT exception table. Maximum and minimum connecting times can be adjusted to test the impact of changes to a flight schedule.

Any large query run in Connections Analyser is sent to the Job Bin where you can see the progress being made to process the query and you can open the report when it is ready. All items in the Job Bin are deleted automatically after 4 days so reports you need to keep should be saved.

Yes, although you have the option to delete them from the Job Bin. You can also save them, send them to another user and export them.

OAG Connections Analyser requires a lot of computer processing, even for relatively small queries and reports. If your query includes a long time period, or double connections, this significantly increases the amount of processing required. Any report which takes over an hour to process is timed out by OAG Connections Analyser.

Look carefully at your query. Almost certainly this will be due to the way you have constructed your query.

Circuity is a term which reflects how far from the Great Circle Distance between the origin and destination is the actual routing when two or more flights connect. It is calculated as:

(aggregate distance of each flight leg) / (great circle distance between origin and destination of route) x 100

A non-stop flight would have a circuity of 100 as the distance of the flight leg would equal the great circle distance between the origin and destination.

A large circuity value applies where the hub airport at which two flights connect is further from the great circle route between the origin and destination of the route. Connections Analyser uses a default circuity of 150.

Connections are created using a predefined minimum connection time for the type of connection at the airport concerned, and a default maximum connection time of 8 hours. The OAG MCT exception tables enable the user to override either, or both, of these are test the impact of different maximum and minimum connecting times.

QSI stands for Quality of Service Index and is a way to compare the attractiveness of one routing against another from a passenger perspective. These are used extensively by airline traffic forecasters who need to understand how the total volume of existing passenger traffic will be redistributed when new flight options are added, or the timing of existing flights are changed. QSI helps calculate market share.

As an example, a coefficient of 2.0 reflects an option which is estimated to be 8 times more attractive to a passenger than a coefficient of 0.25.

The OAG Connections Analyser Glossary contains a detailed listing of QSI parameters and default coefficients used by OAG.

A Phantom Flight is a fictitious flight you create which Connections Analyser treats as if it were part of the schedule database. You can use phantom flights as a means to test ‘what if…’ scenarios such as the impact on connectivity of adding new flights or code-sharing flights with another carrier. Phantom flights need to be created in the My OAG – Customise – Phantom Flights area of Connections Analyser. When you select an airline, the Phantom Flight fields will be automatically populated with the carrier’s typical aircraft type, and seats. Similarly, typical flight duration will automatically populate when you select an origin and destination. These default options can be overridden.

Yes. You can use the Missed Connections report to see what connections would be possible if the flight time was moved forward or backward.

No. You are just logged out of the individual product but still logged on to the OAG Analyser dashboard (portal). If you are inactive on Connections Analyser for 1 hour your session will timeout. Within the dashboard the inactive timeout is 12 hours. One user can have only one active session in the dashboard or Connections Analyser at a time.
